PAMAENS Cartridge Heaters Available in Low to High Watt Densities Chinese Supplier

Short Description:

Cartridge Heaters are used largely used in plastic industry, such as hot runner system, small mold heating ,plastic package ,Medical equipment plastic ,plastic injection molding machine nozzle heating, Package and cartridge is also used in the cigarette industry, footwear industry, thermoforming machinery.

  • FOB Price: US $2- 30 / Piece
  • Min.Order Quantity: 5 Piece/Pieces
  • Supply Ability: 100000 Pieces per Month
  • Shipping: Express, ocean shipping, air shipping
  • Payment Terms: T/T, PAYPAL, WESTERN UNION
  • Production Time: 10-15 days
  • Product Detail

    Product Tags

    Description of Cartridge Heaters

    SHANGHAI PAMAENS manufactures a wide range of cartridge heaters also known
    as immersion heaters for a variety of applications. The size, sheath, leads, terminals, wattage and voltage can be adapted to meet your heating requirement needs.Cartridge Heaters are our most popular product. We make low to medium cartridge and high watt density cartridge heaters. Cartridge heaters provide localized heat to restricted work areas requiring close thermal control. Dies, platens and a variety of other types of processing equipment are efficiently heated. Closely controlled work temperatures up to 1400° F (760 C) are obtained by a combination of heater location and proper wattage output.
    SHANGHAI PAMAENS is a leading electric heating manufacture and can provide heating
    solutions to your specifications to accommodate your application and heating needs. We stock all material for the different diameter units listed in the catalog. Your order, specifying
    the wattage, voltage, diameter, length and lead type is readily and quickly fabricated from our inventory. In addition, many standard sizes are available from our In Stock Cartridge Heaters for immediate delivery.

    Datasheet of Cartridge Heaters Rod

    Sheath material SUS304,321,316,Incoloy800,840
    Wattage Tolerance +5%, -10%
    Resistance tolerance +10%, -5%
    Voltages available 6v – 650v
    Max operating temp 800ºC
    Length tolerance ±1 mm
    Diameter tolerance -0.02mm
    Standard Cold Zone 5-10mm
    Thermocouple Location type J or K are available
    Insulation resistance (cold) ≥ 500 MΩ
    Maximum leakage current (cold) ≤ 0.5 mA


    Feature of Cartridge Heaters Rod

    • Tube diameter: Φ1mm-Φ32mm
    • Tube Material: SS304, SS316, SS321 and NICOLOY800 etc
    • Insulation Material: High-purity MgO
    • Conductor Material: Ni-Cr or Fe-Cr-Al Resistance Heating Wire
    • Wattage density: high/middle/low (5-25w/cm2)
    • Lead Connection Option: Crimped or Swaged leads
    • Lead wire type: 10″ Standard (Teflon/silicone high temperature fiberglass)

    Application of Cartridge Heaters Rod

    •  Injection moulding – Internal heating of nozzles
    •  Hot runner systems – Heating of manifolds
    •  Packaging industry – Heating of cutting bars
    •  Packaging industry – Heating of hot stamps
    •  Laboratories – Heating of analytical equipment
    •  Medical: Dialysis, Sterilization, Blood Analyzer, Nebulizer, Blood/Fluid Warmer, Temperature Therapy
    •  Telecommunications: Deicing, Enclosure Heater
    •  Transportation: Oil/Block Heater, Aircraft Coffee Pot Heaters,
    •   Food Service: Steamers, Dish Washers,
    •   Industrial: Packaging Equipment, Hole Punches, Hot Stamp.

    Reference pictures of Cartridge Heaters Rod
    Cartridge heater-28.jpg Cartridge heater-33.jpg
    Cartridge heater-60.jpg Cartridge heater-72.jpg
    Cartridge heater-38.jpg Cartridge heater-69.jpg
    Cartridge heater-101.jpg Cartridge heater-99.jpg
    Cartridge heater-112.jpg Cartridge heater-119.jpg
    Cartridge heater-153.jpg Cartridge heater-159.jpg
    Cartridge heater-169.jpg insulation jacket-187.jpg
    Packaging & Shipping

    cartridge-material -12.jpg

    Our Services



    Company Information

    Shanghai PAMAENS Technology Co., Ltd located in Shanghai, specialized in researching, developping and manufacturing heaters, plastic machinery accessaries and energy saving products. We have strong researching and developping team, many of our engineers have more than ten years experience on manufacturing heaters, and we have stict quality control system, and a team of professional sales people, so no matter manufacturing process, products quality, or prices, we believe few factories could compare with us in China.



    1. Diameter
    2. Length
    3. Voltage
    4. Power
    5. Lead & Fitting (connection and fitting type, leads length)
    6. Quantity
    Question and reply you may concern
    About us?
    We are factory and exporter, own ISO9001 and  Research and development team and QC department.
    Do you accept customized?
    Yes , we are ready to turn your great design into perfect products, of course, your special design will be completely confidential. At same time, we are good designer ourselves.
    How is your shipping?
    We could send the goods on your instruction, if you do not want to handle shipping yourself, we could handle shipping for you. Shortest delivery time and lowest freight are our target, so the freight we provided are always the best, because we check many forwarders and get the best freight for you.
    Why choose us?
    Lowest default rateOne to two year warrantyBest and on time after sale serviceYou are worried, we would like you to think
